M250HAN01. A is a 24.5-inch a-Si TFT-LCD LCD module product launched by AUO. It is equipped with WLED backlight, no backlight driver, and no touch. The working temperature of this product is 0-50 ° C, the storage temperature is -20~60 ° C, and the vibration resistance is 1.5G (14.7 m/s ²). Its typical feature screen library is summarized as: sRGB, 3-side borderless, 240Hz, white LED backlight, inverted terminals, surface matte, 240Hz, 5ms GTG, sRGB99%, 400nits, 3S BLL, eDP4L HBR2. Based on its features, this model is recommended for use in computer monitors, games, and other products. According to the product specification document Ver1.2 released by AU on March 11, 2021, M250HAN01. A has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 543.744 (width) × 302.616 (height) mm, and its appearance size is 552.49 (width) × 319.58 (height) × 13.95 (thickness) mm. The surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 1.71/1.80Kgs (Typ./Max.). In terms of backlight, this product adopts a 17S4P WLED side entry light source with a lifespan of 30K hours, without backlight driver. M250HAN01. A adopts eDP (4 Lanes) signal interface, with a total of 51 pins, connected by terminals, and a screen driving voltage of 12.0V (Typ.). Its typical vertical refresh rate Fv is 240Hz.

The display resolution of LM245WFA-SSA1 is 1920 (RGB) × 1080 (FHD), with an aspect ratio of 16:9 (width: height), and the pixels are arranged vertically in RGB stripes. Its display area size is 543.744 × 302.616 (width × height) mm, and its appearance size is 552.5 × 319.6 (width × height) × 13.95 (thickness) mm. The surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 1.79/1.87Kgs (Typ./Max.). In terms of backlight, this product adopts a side entry light source with 4 strings × 2CN WLED emission, and the service life of the light source is 30K hours, without backlight driver. LM245WFA-SSA1 adopts eDP (8 Lanes) signal interface, with a total of 60 pins, connected by terminals, and a screen driving voltage of 10.0V (Typ.). Its typical vertical refresh rate Fv is 480Hz.

M250HTN01. J has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in a vertical RGB stripe pattern. Its display area size is 543.744 × 302.616 (width × height) mm, the visible size is 546.94 × 305.82 (width × height) mm, the appearance size is 556 × 323.2 (width × height) × 14.25 (thickness) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 2.18/2.29Kg (Typ./Ma.). In terms of backlight, this product adopts a 17S4P WLED side entry light source with a lifespan of 30K hours, without backlight driver. M250HTN01. J adopts eDP (8 Lanes) signal interface, with a total of 51 pins, connected by terminals, and a screen driving voltage of 12.0V (Typ.). Its typical vertical refresh rate Fv is 360Hz.

LM245WFA-SSA1 24.5" LCD Screen Display IPS FHD
