LTM236FL01 is a 23.6 inch LCD module product launched by Samsung Display Co., Ltd. (Samsung) using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. According to the product specification sheet with version number RevP0.0 released by Samsung on March 12, 2014, the LTM236FL01 has a display resolution of 3840 (RGB) × 2160 (UHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 521.28 × 293.22 (width × height) mm, the visible size is 525.4 × 297.3 (width × height) mm, the appearance size is 544.8 × 320.5 (width × height) × 11 (thickness) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 2.86Kg (Max.). In terms of backlight, this product uses a 16S4P WLED side entry light source (bottom) with a lifespan of 30K hours, without backlight driver. LTM236FL01 adopts eDP (4 Lanes) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 60Hz.

The LTM230HT10 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 509.76 × 286.74 (width × height) mm, the visible size is 513.8 × 290.8 (width × height) mm, the appearance size is 534 (width) × 311.7 (height) × 10.7 (thickness) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 1.60Kgs (Max.). In terms of backlight, this product adopts a side entry light source (right side) with 11S3P WLED emission, and the service life of the light source is 30K hours, without backlight driver. The LTM230HT10 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The M236HGE-L10 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 521.28 (width) × 293.22 (height) mm, the appearance size is 544.8 (width) × 320.5 (height) × 11.9 (thickness) mm, the visible size is 525.22 (width) × 297.22 (height) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 2.51/2.61Kg (Typ./max.). In terms of backlight, this product adopts a 9S4P WLED side entry light source (bottom) with a lifespan of 30K hours, without backlight driver. The M236HGE-L10 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The M236HGE-L20 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 521.28 × 293.22 (width × height) mm, the visible size is 525.22 × 297.22 (width × height) mm, the appearance size is 544.8 (width) × 320.5 (height) × 11.5 (thickness) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 2.31/2.41Kg (Typ./Max.). In terms of backlight, this product adopts a side entry light source with 4 strings WLED emission (on the right), and the service life of the light source is 40K hours, without backlight driver. The M236HGE-L20 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The M236HJJ-L31 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 521.28 × 293.22 (width × height) mm, the visible size is 525.22 × 297.22 (width × height) mm, the appearance size is 544.8 × 320.5 (width × height) × 11.5 (thickness) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 2.31 ± 0.11Kg. In terms of backlight, this product adopts a side entry light source (left) with 4 strings WLED emission, and the service life of the light source is 40K hours, without backlight driver. M236HJJ-L31 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The 23.6 inch LCD module product using a-Si TFT-LCD technology is equipped with WLED backlight, no backlight driver, and no touch.
