The LTM230HT10 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 509.76 × 286.74 (width × height) mm, the visible size is 513.8 × 290.8 (width × height) mm, the appearance size is 534 (width) × 311.7 (height) × 10.7 (thickness) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 1.60Kgs (Max.). In terms of backlight, this product adopts a side entry light source (right side) with 11S3P WLED emission, and the service life of the light source is 30K hours, without backlight driver. The LTM230HT10 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The M236HGE-L10 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 521.28 (width) × 293.22 (height) mm, the appearance size is 544.8 (width) × 320.5 (height) × 11.9 (thickness) mm, the visible size is 525.22 (width) × 297.22 (height) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 2.51/2.61Kg (Typ./max.). In terms of backlight, this product adopts a 9S4P WLED side entry light source (bottom) with a lifespan of 30K hours, without backlight driver. The M236HGE-L10 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The M236HGE-L20 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 521.28 × 293.22 (width × height) mm, the visible size is 525.22 × 297.22 (width × height) mm, the appearance size is 544.8 (width) × 320.5 (height) × 11.5 (thickness) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 2.31/2.41Kg (Typ./Max.). In terms of backlight, this product adopts a side entry light source with 4 strings WLED emission (on the right), and the service life of the light source is 40K hours, without backlight driver. The M236HGE-L20 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The 23.6 inch LCD module product using a-Si TFT-LCD technology is equipped with WLED backlight, no backlight driver, and no touch.

The 23.6 inch LCD glass product using a-Si TFT-LCD technology has no backlight and no touch. Its typical features are: borderless on 3 sides, curved display, 165Hz, matte surface, R1500. Its working temperature is 0~50 ° C and storage temperature is -20~60 ° C. This model is suitable for use in computer monitors
