The LB315WRM-SVA3 (also known as LB315WRM (SV) (A3)) launched by LG Display is a 32.0-inch LCD module product using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. The typical features of the screen library are DCI-P3, sRGB, ultra-high brightness, white LED backlight, inverted terminals, 10 bit grayscale, and matte surface. Its working temperature is 0-50 ° C and storage temperature is -20~60 ° C. This model is suitable for use in medical imaging. According to the product specification sheet with version number Ver1.0 released by LG Display on June 20, 2025, the LB315WRM-SVA3 has a display resolution of 3840 (RGB) × 2160 (UHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 697.306 × 392.234 (width × height) mm, and its appearance size is 730.7 (width) × 425.2 (height) mm. The surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 6.00/6.30Kgs (Typ./Max.). In terms of backlighting, this product uses a WLED direct light source with a lifespan of 30K hours and does not include backlight drivers. LB315WRM-SVA3 adopts a V-by-One 8 lanes signal interface, with a total of 51 pins, connected by terminals, and a screen driving voltage of 10V (Typ.). Its typical vertical refresh rate Fv is 60Hz.

LB315WR6-SSZ1 (alias: LB315WR6 (SS) (Z1)) is a 32.0-inch a-Si TFT-LCD LCD module product launched by LG Display. It is equipped with WLED backlight, no backlight driver, and no touch. This product has a working temperature of 5~50 ° C and a storage temperature of -20~60 ° C. Its typical feature screen library is summarized as sRGB, ultra-high brightness, white LED backlight, inverted terminals, 10 bit grayscale, and surface matte. Based on its feature screen library, this model is recommended for use in medical imaging and other products. According to the product specification sheet with version number Ver1.0 released by LG Display on January 28, 2022, the LB315WR6-SSZ1 has a display resolution of 3840 (RGB) × 2160 (UHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 697.306 (width) × 392.234 (height) mm, the external dimensions are 730.7 (width) × 425.2 (height) × 23.7 (thickness) mm, the visible dimensions are 701.7 (width) × 398.36 (height) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 5.90/6.20Kgs (Typ./Max.). In terms of backlighting, this product uses a WLED direct light source with a lifespan of 30K hours and does not include backlight drivers. LB315WR6-SSZ1 adopts eDP (4 Lanes) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 10.0V (Typ.). Its typical vertical refresh rate Fv is 60Hz.

The MV315QUM-N20 launched by BOE is a 32.0-inch LCD module product using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. Its typical features are summarized as: DCI-P3, sRGB, borderless on 3 sides, white LED backlight, inverted terminals, 10 bit grayscale, matte surface, 3-side borderless, ES7.0/TCO8.0 Compliant, for LG 32UN650. Its working temperature is 0-50 ° C, storage temperature is -20~60 ° C, and vibration resistance is 1.2G (11.76 m/s ²). This model is suitable for use with computer monitors. According to the product specification document with version number Rev. O released by BOE on June 24, 2020, the MV315QUM-N20 has a display resolution of 3840 (RGB) × 2160 (UHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 697.306 × 392.234 (width × height) mm, and its appearance size is 709.4 (width) × 412 (height) × 15.2 (thickness) mm. The surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 4.55Kg (Typ.). In terms of backlight, this product adopts a side entry light source (bottom) with 11S4P × 2CN WLED emission, and the service life of the light source is 30K hours, without backlight driver. MV315QUM-N20 adopts eDP (4 Lanes) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 10.0V (Typ.). Its typical vertical refresh rate Fv is 60Hz.

LM315WR7-SSA1 (alias: LM315WR7 (SS) (A1)) is a 32.0-inch a-Si TFT-LCD LCD module product launched by LG Display. It is equipped with WLED backlight, no backlight driver, and no touch. The working temperature of this product is 0-50 ° C, the storage temperature is -20~60 ° C, and the vibration resistance is 1.0G (9.8 m/s ²). Its typical features are summarized as: DCI-P3, sRGB, 4-sided borderless, 120Hz, white LED backlight, inverted terminals, 10 bit grayscale, surface matte, 4-side borderless, LBL, Reverse type, TCO9.0, ES8.0. Based on its feature screen library, this model is recommended for use in computer monitors, industrial, medical imaging and other products. According to the product specification sheet with version number Ver1.0 released by LG Display on October 24, 2024, the LM315WR7-SSA1 has a display resolution of 3840 (RGB) × 2160 (UHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 697.306 (width) × 392.234 (height) mm, and its appearance size is 709.4 (width) × 405.95 (height) × 16 (thickness) mm. The surface treatment is matte (Haze 35%), hard coating (3H), anti reflection treatment, and the net weight of the product is 3.30/3.46Kgs (Typ./Max.). In terms of backlight, this product adopts a side entry light source (bottom) with 11S4P × 2CN WLED emission, and the service life of the light source is 30K hours, without backlight driver. LM315WR7-SSA1 adopts eDP (8 Lanes) signal interface, with a total of 60 pins, connected by terminals, and a screen driving voltage of 10.0V (Typ.). Its typical vertical refresh rate Fv is 120Hz.

TPM315WQ1-DVR01.U 31.5" LCD Screen Display IPS FHD

TPM315WQ1-DVR01.A 31.5" LCD Screen Display IPS FHD

Typical features are summarized as: DCI-P3, sRGB, HDR600, borderless on 3 sides, high brightness, white LED backlight, inverted terminals, 10 bit grayscale, surface matte, 3-side borderless, HDR600, ES8.0/CEL1/CEC compliant. Based on its features, this model is recommended for use in products such as computer monitors.

M315RVR01.9 31.5"LCD Screen Display IPS FHD
