LM215WF3-SLS2 (alias: LM215WF3 (SL) (S2)) is a 21.5-inch a-Si TFT-LCD LCD module product launched by LG Display. It is equipped with WLED backlight, no backlight driver, and no touch. The working temperature of this product is 0-50 ° C, the storage temperature is -20~60 ° C, and the vibration resistance is 1.0G (9.8 m/s ²). Its typical feature screen library is summarized as: white LED backlight, inverted terminals, and matte surface. Based on its feature screen library, this model is recommended for use in computer monitors, industrial, healthcare, and other products. According to the product specification sheet with version number Rev1.0 released by LG Display on July 16, 2020, the LM215WF3-SLS2 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 476.064 (width) × 267.786 (height) mm, the external dimensions are 497.6 (width) × 292.2 (height) × 11 (thickness) mm, the visible dimensions are 479.8 (width) × 271.3 (height) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 1.69/1.77Kg (Typ./Max.). In terms of backlight, this product uses a 17S2P WLED side entry light source (on the right) with a lifespan of 30K hours and does not include backlight drivers. LM215WF3-SLS2 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The DV215FHM-NN0 launched by BOE is a 21.5-inch LCD module product using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. Its typical features are summarized as follows: white LED backlight, inverted terminals, matte surface, Energy Star 7.0 compliance. Its working temperature is 0~50 ° C and storage temperature is -20~60 ° C. This model is suitable for industrial and digital signage applications. According to the product specification sheet with version number Rev.P1 released by BOE on October 30, 2018, the DV215FHM-NN0 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 476.064 × 267.786 (width × height) mm, the visible size is 479.8 × 271.2 (width × height) mm, the appearance size is 495.6 (width) × 292.2 (height) × 11.2 (thickness) mm, and the surface treatment is matte, Hard coating (3H)， The net weight of the product is 1.97Kg (Typ.). In terms of backlight, this product adopts a side entry light source (bottom) with 24S3P WLED emission, and the service life of the light source is 30K hours, without backlight driver. DV215FHM-NN0 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 60Hz.

G215HAN01.2 is a 21.5-inch LCD module product launched by AU Optronics Corporation (AUO) using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. According to the product specification sheet with version number Ver1.2 released by AU on February 18, 2019, G215HAN01.2 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 476.064 × 267.786 (width × height) mm, the visible size is 479.8 × 271.3 (width × height) mm, the appearance size is 497.6 × 292.2 (width × height) × 11 (thickness) mm, and the surface treatment is matte, Hard coating (3H)， The net weight of the product is 1.74Kg (Typ.). In terms of backlight, this product uses a 12S4P WLED side entry light source (on the right) with a lifespan of 50K hours and does not include backlight drivers. G215HAN01.2 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 60Hz.

DV215FHM-R10 is a 21.5-inch a-Si TFT-LCD LCD module product launched by BOE. It is equipped with WLED backlight, no backlight driver, and no touch. The working temperature of this product is -20~60 ° C, the storage temperature is -30~70 ° C, and the vibration resistance is 1.0G (9.8 m/s ²). Its typical feature screen library is summarized as: ultra-high brightness, white LED backlight, lifespan greater than 50000 hours, inverted terminals, and matte surface. Based on its feature screen library, this model is recommended for industrial, digital signage, outdoor high brightness and other products. According to the product specification book with version number Ver. O released by BOE on October 13, 2022, the DV215FHM-R10 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 17:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 478.656mm (width) x 260.28mm (height), and its appearance size is 499 mm (width) x 286.2 mm (height) x 15.2 mm (thickness). The visible size is 481.1 mm (width) x 262.7 mm (height), and the surface treatment is matte, Hard coating (3H)， The net weight of the product is 2.00Kgs (Typ.). In terms of backlight, this product uses 17S4P × 2CN WLED side entry light sources (top and bottom), with a lifespan of 50K hours and no backlight driver included. DV215FHM-R10 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 60Hz.

LM215WF3-SLS1 (also known as LM215WF3 (SL) (S1)) is a 21.5-inch LCD module product launched by LG Display, which uses a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. According to the product specification sheet with version number Ver1.0 released by LG Display on April 25, 2016, the LM215WF3-SLS1 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 476.064 × 267.786 (width × height) mm, visible size is 479.8 × 271.3 (width × height) mm, appearance size is 497.6 × 292.2 (width × height) × 11 (thickness) mm, surface treatment is matte (Haze 25%), Hard coating (3H), product net weight is 1.69/1.77Kg (Typ./Max.). In terms of backlight, this product uses a 17S2P WLED side entry light source (on the right), with a lifespan of 30K hours and no backlight driver included. LM215WF3-SLS1 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The G215HAN01.501 launched by AUO is a 21.5-inch LCD module product using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. Summarizing its typical features are: white LED backlight with a lifespan of over 50000 hours, inverted terminals, and a matte surface. Its working temperature is -10~60 ° C, storage temperature is -20~60 ° C, and vibration resistance is 1.5G (14.7 m/s ²). This model is suitable for industrial and medical imaging applications. According to the product specification sheet with version number Final Ver0.3 released by AU on November 22, 2021, G215HAN01.501 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 476.064 × 267.786 (width × height) mm, the visible size is 479.8 × 271.3 (width × height) mm, the appearance size is 497.6 (width) × 292.2 (height) × 11.1 (thickness) mm, and the surface treatment is matte, Hard coating (3H)， The net weight of the product is 1.74Kg (Typ.). In terms of backlight, this product uses a 16S4P WLED side entry light source (top) with a lifespan of 50K hours, without backlight driver. G215HAN01.501 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 60Hz.

The M215HGE-L33 launched by Chimei Innolux is a 21.5-inch LCD module product using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. The typical features of the screen library are: white LED backlight, terminal mounting, surface matte finish, and TCO8.0. Its working temperature is 0-50 ° C, storage temperature is -20~60 ° C, and vibration resistance is 1.5G (14.7 m/s ²). This model is suitable for use with computer monitors. According to the product specification document Rev.C1_Ver3.2 released by Chimei Innolux on August 3, 2021, the M215HGE-L33 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 476.64 × 268.11 (width × height) mm, the visible size is 479.8 × 271.3 (width × height) mm, the appearance size is 495.6 (width) × 292.3 (height) × 11.5 (thickness) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 1.72 ± 0.17Kgs. In terms of backlight, this product adopts a side entry light source with 4 strings WLED emission (on the right), and the service life of the light source is 30K hours, without backlight driver. M215HGE-L33 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The display resolution of LM215WF3-SLC1 is 1920 (RGB) × 1080 (FHD), with an aspect ratio of 16:9 (width: height), and the pixels are arranged vertically in RGB stripes. Its display area size is 475.2 (width) × 267.3 (height) mm, and its appearance size is 495.6 (width) × 292.2 (height) × 10.7 (thickness) mm. The visible size is 478.8 (width) × 271.3 (height) mm, and the surface treatment is matte, Hard coating (3H)， The net weight of the product is 1.19/1.25kgs (Typ./Max.). In terms of backlight, this product uses a 13S4P WLED side entry light source (bottom) with a lifespan of 30K hours and does not include backlight drivers. LM215WF3-SLC1 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.
