The LB270WFM-SLA1 (also known as LB270WFM (SL) (A1)) launched by LG Display is a 27.0-inch LCD module product using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. Screen Library summarizes its typical features as: sRGB, ultra-high brightness, white LED backlight, inverted terminals, 10 bit grayscale, surface matte, 1000nit, sRGB, 1000:1, true 10 bit, LVDs, Case Top. Its working temperature is 0-50 ° C, storage temperature is -20~60 ° C, and vibration resistance is 1.0G (9.8 m/s ²). This model is suitable for use in medical imaging. According to the product specification sheet with version number Ver1.0 released by LG Display on January 7, 2019, the LB270WFM-SLA1 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 597.888 × 336.312 (width × height) mm, the visible size is 601.3 × 339.7 (width × height) mm, the appearance size is 622.4 (width) × 364.2 (height) × 17.85 (thickness) mm, the surface treatment is haze 25%, hard coating (3H), and the net weight of the product is 2.84/2.98Kg (Typ./Max.). In terms of backlight, this product uses 18S4P × 2CN WLED side entry light sources (top and bottom), with a lifespan of 30K hours and no backlight driver included. LB270WFM-SLA1 adopts LVDS (2 ch, 10 bit) signal interface, with a total of 51 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 60Hz.

The LB270WF1-SLA1 (also known as LB270WF1 (SL) (A1)) launched by LG Display is a 27.0-inch LCD module product using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. Screen Library summarizes its typical features as: ultra-high brightness, white LED backlight, inverted terminals, 10 bit grayscale, surface matte, 1000nit, sRGB, 1000:1, 10 bit, LVDs, Case Top. Its working temperature is 0-50 ° C, storage temperature is -20~60 ° C, and vibration resistance is 1.0G (9.8 m/s ²). This model is suitable for use in medical imaging. According to the product specification sheet with version number Ver0.4 released by LG Display on January 19, 2018, the LB270WF1-SLA1 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 597.888 × 336.312 (width × height) mm, the visible size is 601.3 × 339.7 (width × height) mm, the appearance size is 622.4 (width) × 364.2 (height) × 17.85 (thickness) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is TBD. In terms of backlight, this product uses 18S4P × 2CN WLED side entry light sources (top and bottom), with a lifespan of 30K hours and no backlight driver included. LB270WF1-SLA1 adopts LVDS (2 ch, 10 bit) signal interface, with a total of 51 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 60Hz.

MV270FHM-N60 is a 27.0-inch LCD module product launched by BOE Technology Group Co., Ltd. (BOE) using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. According to the product specification document with version number Rev. 0 released by BOE on November 15, 2021, the MV270FHM-N60 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 597.888 × 336.312 (width × height) mm, the visible size is 601.89 × 340.1 (width × height) mm, the appearance size is 611.5 × 355.8 (width × height) × 15.2 (thickness) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 3.49Kg (Typ.). In terms of backlight, this product uses a 22S4P WLED side entry light source (bottom) with a lifespan of 30K hours, without backlight driver. MV270FHM-N60 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

MV270FHM-N20 is a 27.0-inch LCD module product launched by BOE Technology Group Co., Ltd. (BOE) using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. According to the product specification sheet with version number Rev.P2 released by BOE on August 24, 2016, the MV270FHM-N20 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 597.888 × 336.312 (width × height) mm, the visible size is 601.9 × 340.4 (width × height) mm, the appearance size is 611.5 × 355.8 (width × height) × 13.5 (thickness) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 3.49Kg. In terms of backlight, this product adopts a side entry light source (bottom) with 18S4P WLED emission, and the service life of the light source is 30K hours, without backlight driver. MV270FHM-N20 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

SG2701B01-7 is a 27.0-inch LCD glass product launched by Shenzhen Huaxing Optoelectronics Technology Co., Ltd. (CSOT) using a-Si TFT-LCD technology. It has no backlight, no touch, and has been bonded with 6 source chips driver IC. According to the product specification book Ver2.5 released by CSOT on July 6, 2021, SG2701B01-7 Ver.2.5 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged vertically in RGB stripes. Its display area size is 597.888 × 336.312 (width × height) mm, and its appearance size is 608.888 × 348.337 (width × height) × 1.14 (thickness) mm. The surface treatment is matte (Haze 25%), and the net weight of the product is 700g (Typ.), using a glass substrate of 0.40+0.40mm. This product has no backlight. SG2701B01-7 Ver.2.5 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 12.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The M270HVR01.0 CELL is a 27.0-inch LCD glass product launched by AU Optronics Inc. (AUO) using a-Si TFT-LCD technology. It has no backlight, no touch, and has been bonded with a 6-source chip driver IC. According to the product specification book T0_Ver1.2 released by AUO on January 27, 2022, the M270HVR01.0 CELL has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 596.736 × 335.664 (width × height) mm, and its appearance size is 608.888 × 350.24 (width × height) × 1.14 (thickness) mm. The surface treatment is matte, Hard coating (4H)， The product has a net weight of 600g (Typ.) and uses a glass substrate of 0.40+0.40mm. This product has no backlight. The M270HVR01.0 CELL adopts LVDS (4 ch, 8-bit) signal interface, with a total of 61 pins, connected by terminals, and a screen driving voltage of 12.0V (Typ.). Its typical vertical refresh rate Fv is 165Hz.

SG2701B01-9 is a 27.0-inch a-Si TFT-LCD liquid crystal glass product launched by CSOT, which has no backlight and no touch. This product operates at a temperature range of 0~50 ° C and has a storage temperature range of -20~60 ° C. Its typical feature screen library is summarized as sRGB, borderless on 3 sides, curved display, 240Hz, matte surface, 240Hz, R1500, 3BDLS. Based on its features, this model is recommended for use in computer monitors, games, and other products. This product has been bonded with 6 source chips driver IC. According to the product specification document Ver2.5 released by CSOT on September 22, 2021, SG2701B01-9 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 597.888 (width) × 336.312 (height) mm, and its appearance size is 608.888 (width) × 348.337 (height) × 1.13 (thickness) mm. The surface treatment is matte (Haze 25%), Hard coating (3H), and it uses a glass substrate of 0.40+0.40 mm. This product has no backlight. SG2701B01-9 adopts V-by-One 8 lanes signal interface, with a total of 51 pins, connected by terminals, and a screen driving voltage of 12.0V (Typ.). Its typical vertical refresh rate Fv is 240Hz.

The M270QAN07.2 launched by AU is a 27.0-inch LCD module product using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. Summarizing its typical features are: HDR600, borderless on 3 sides, white LED backlight, 10 bit grayscale, surface matte, 160 Hz, 5ms GTG, Adobe 99%, 400nits, HDR600 (96 zones), 3S BLL, LBL, eDP 8L HBR2。 Its working temperature is 0-50 ° C, storage temperature is -20~60 ° C, and vibration resistance is 1.5G (14.7 m/s ²). This model is suitable for use in computer monitors, gaming.. M270QAN07.2 has a display resolution of 3840 (RGB) × 2160 (UHD), an aspect ratio of 16:9 (width: height), and pixels arranged in a vertical RGB stripe pattern. Its display area size is 596.16 × 335.34 (width × height) mm, with a surface treatment of matte (Haze 25%) and Hard coating (3H). In terms of backlight, this product uses a WLED side entry light source with a lifespan of 30K hours and does not include backlight drivers. M270QAN07.2 adopts eDP (8 Lanes) signal interface. Its typical vertical refresh rate Fv is 160Hz.
