The MV270FHB-N60 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 597.888 (width) × 336.312 (height) mm, and its appearance size is 607.048 (width) × 346.642 (height) × 1.32 (thickness) mm. The surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 620g (Typ.), using a glass substrate of 0.50+0.50mm. This product has no backlight. MV270FHB-N60 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The M270KCJ-K7B Rev. C1 has a display resolution of 2560 (RGB) × 1440 (Quad HD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 596.736 × 335.664 (width × height) mm, and its appearance size is 608.8 (width) × 355.13 (height) × 13.8 (thickness) mm. The surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 2.58/2.87/3.01Kg (Min./Typ./Max.). In terms of backlight, this product adopts a side entry light source (bottom) with 4 strings WLED emission, and the service life of the light source is 30K hours, without backlight driver. M270KCJ-K7B Rev. C1 adopts V-by-One 8 lanes signal interface, with a total of 51 pins, connected by terminals, and a screen driving voltage of 12.0V (Typ.). Its typical vertical refresh rate Fv is 165Hz.

The MV270QUM-N20 has a display resolution of 3840 (RGB) × 2160 (UHD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 596.736 × 335.664 (width × height) mm, and its appearance size is 608.8 × 353.3 (width × height) × 13.9 (thickness) mm. The surface treatment is matte (Haze 25%), hard coating (3H), and the net weight of the product is 3.22Kgs (Typ.). In terms of backlight, this product uses a 19S4P WLED side entry light source (bottom) with a lifespan of 30K hours and does not include backlight drivers. The MV270QUM-N20 adopts eDP (4 Lanes) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 10.0V (Typ.). Its typical vertical refresh rate Fv is 60Hz.

The LTM270DL02 has a display resolution of 2560 (RGB) × 1440 (Quad HD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 596.736 (width) × 335.664 (height) mm, and its appearance size is 630 (width) × 368.2 (height) × 16.9 (thickness) mm. The visible size is 601.7 (width) × 340.7 (height) mm, and the net weight of the product is 3.20Kgs (Max.). In terms of backlight, this product uses a 20S4P WLED side entry light source (bottom) with a lifespan of 30K hours, without backlight driver. LTM270DL02 adopts LVDS (4 ch, 8-bit) signal interface, with a total of 66 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The LTM270DL07-M01 has a display resolution of 2560 (RGB) × 1440 (Quad HD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 596.736 × 335.664 (width × height) mm, and its appearance size is 626.3 × 362.6 (width × height) × 9.6 (thickness) mm. The surface treatment is matte (Haze 1%), and the net weight of the product is TBD. In terms of backlight, this product adopts a WLED side entry light source with a lifespan of 15K hours, including LED driver. LTM270DL07-M01 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 70 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 65Hz.

The display resolution of LTM270DL11 is 2560 (RGB) × 1440 (Quad HD), with an aspect ratio of 16:9 (width: height), and the pixels are arranged in vertical RGB stripes. Its display area size is 596.736 (width) × 335.664 (height) mm, and its appearance size is 608.6 (width) × 348.3 (height) × 16 (thickness) mm. The surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 3.10 Kgs (Max.). In terms of backlight, this product adopts a WLED side entry light source with a lifespan of 40K hours and does not include backlight drivers. LTM270DL11-C01 adopts LVDS (4 ch, 8-bit) signal interface, with a total of 61 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 65Hz.

The LTM270HL02 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 597.888 × 336.312 (width × height) mm, the visible size is 602.0 × 340.4 (width × height) mm, the appearance size is 630 × 368.2 (width × height) × 12.2 (thickness) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 3.20Kgs (Max.). In terms of backlighting, this product uses a 13S3P WLED side entry light source (on the right), which has a lifespan of 40K hours and does not include backlight drivers. LTM270HL02 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

M270DAN02.8 has a display resolution of 2560 (RGB) × 1440 (Quad HD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 596.736 (width) × 335.664 (height) mm, and its appearance size is 607.5 (width) × 354.09 (height) × 13.9 (thickness) mm. The surface treatment is matte, Hard coating (3H)， The net weight of the product is 3.20Kg (Typ.). In terms of backlight, this product adopts a 17S4P WLED side entry light source with a lifespan of 30K hours, without backlight driver. M270DAN02.8 adopts LVDS (4 ch, 10 bit) signal interface, with a total of 70 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.
