The M240HW02 V1 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 531.36 × 298.89 (width × height) mm, the visible size is 535.36 × 302.89 (width × height) mm, the appearance size is 556 (width) × 323.2 (height) × 11.5 (thickness) mm, and the surface treatment is matte, Hard coating (3H)， The net weight of the product is 2.05Kg (Typ.). In terms of backlight, this product adopts a 15S4P WLED side entry light source (bottom) with a lifespan of 30K hours, without backlight driver. M240HW02 V1 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The M240HW01 V2 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 531.36 × 298.89 (width × height) mm, the visible size is 535.4 × 302.9 (width × height) mm, the appearance size is 556 (width) × 323.2 (height) × 16.8 (thickness) mm, and the surface treatment is matte, Hard coating (3H)， The net weight of the product is 2.76Kg (Typ.). In terms of backlight, this product uses 4 pieces of CCFL emitting side entry light sources (top and bottom), with a lifespan of 50K hours and no backlight driver included. M240HW01 V2 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The M240HW01 V8 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 531.36 (width) × 298.89 (height) mm, and its appearance size is 556 (width) × 323.2 (height) × 14.9 (thickness) mm. The visible size is 535.4 (width) × 303.0 (height) mm, and the surface treatment is matte, Hard coating (3H)， The net weight of the product is 2.20Kgs (Typ.). In terms of backlight, this product uses a 14S4P WLED side entry light source (bottom) with a lifespan of 30K hours, without backlight driver. The M240HW01 V8 adopts LVDS (4 ch, 8-bit) signal interface, with a total of 66 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 120Hz.

The MV240WUM-NX3 has a display resolution of 1920 (RGB) × 1200 (WUXGA), an aspect ratio of 16:10 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 518.4 × 324 (width × height) mm, and its external dimensions are 528.2 (width) × 337.82 (height) mm. The surface treatment is matte (Haze 25%), hard coating (3H), and the net weight of the product is 2.04Kgs (Typ.). In terms of backlighting, this product uses a WLED side entry light source (bottom) with a lifespan of 30K hours and does not include backlight drivers. MV240WUM-NX3 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 100Hz.

The display resolution of M240HTN01.2 is 1920 (RGB) × 1080 (FHD), with an aspect ratio of 16:9 (width: height), and the pixels are arranged vertically in RGB stripes. Its display area size is 531.36 × 298.89 (width × height) mm, the visible size is 535.4 × 303.0 (width × height) mm, the appearance size is 556 (width) × 323.2 (height) × 12 (thickness) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 1.89 ± 0.08Kgs. In terms of backlight, this product uses a 9S4P WLED side entry light source (on the right) with a lifespan of 30K hours and does not include backlight drivers. M240HTN01.2 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The M240HW01 VD display has a resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 531.36 × 298.89 (width × height) mm, the visible size is 535.4 × 303.0 (width × height) mm, the appearance size is 556 (width) × 323.2 (height) × 12 (thickness) mm, and the surface treatment is matte, Hard coating (3H)， The net weight of the product is 2.53/2.61Kg (Typ./max.). In terms of backlight, this product uses a 20S4P WLED side entry light source (bottom) with a lifespan of 30K hours, without backlight driver. M240HW01 VD adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The M240HW01 VD display has a resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 531.36 × 298.89 (width × height) mm, the visible size is 535.4 × 303.0 (width × height) mm, the appearance size is 556 (width) × 323.2 (height) × 12 (thickness) mm, and the surface treatment is matte, Hard coating (3H)， The net weight of the product is 2.53/2.61Kg (Typ./max.). In terms of backlight, this product uses a 20S4P WLED side entry light source (bottom) with a lifespan of 30K hours, without backlight driver. M240HW01 VD adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The M240HW01 V8 has a display resolution of 1920 (RGB) × 1080 (FHD), an aspect ratio of 16:9 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 531.36 (width) × 298.89 (height) mm, and its appearance size is 556 (width) × 323.2 (height) × 14.9 (thickness) mm. The visible size is 535.4 (width) × 303.0 (height) mm, and the surface treatment is matte, Hard coating (3H)， The net weight of the product is 2.20Kgs (Typ.). In terms of backlight, this product uses a 14S4P WLED side entry light source (bottom) with a lifespan of 30K hours, without backlight driver. The M240HW01 V8 adopts LVDS (4 ch, 8-bit) signal interface, with a total of 66 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 120Hz.
