The display resolution of M170ETN01.1 is 1280 (RGB) × 1024 (SXGA), with an aspect ratio of 5:4 (width: height), and the pixels are arranged in RGB vertical stripes. Its display area size is 337.92 × 270.336 (width × height) mm, the visible size is 341.72 × 274.14 (width × height) mm, the appearance size is 358.5 × 296.5 (width × height) × 10.8 (thickness) mm, and the surface treatment is matte, Hard coating (3H)， The net weight of the product is 1.27Kg (Typ.). In terms of backlight, this product adopts a 9S4P WLED side entry light source (bottom) with a lifespan of 30K hours, without backlight driver. M170ETN01.1 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The M170EG01 V9 has a display resolution of 1280 (RGB) × 1024 (SXGA), an aspect ratio of 5:4 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 337.92 × 270.336 (width × height) mm, the visible size is 341.6 × 274.0 (width × height) mm, the appearance size is 358.5 (width) × 296.5 (height) × 17.5 (thickness) mm, the surface treatment is mirror (Haze 0%), Hard coating (2H), and the net weight of the product is 1.90Kgs (Typ.). In terms of backlight, this product uses 4 pieces of CCFL emitting side entry light sources (top and bottom), with a lifespan of 50K hours and no backlight driver included. M170EG01 V9 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The M170EG01 VD display has a resolution of 1280 (RGB) × 1024 (SXGA), an aspect ratio of 5:4 (width: height), and pixels arranged in vertical RGB stripes. Its display area size is 337.92 × 270.336 (width × height) mm, the visible size is 341.6 × 274.0 (width × height) mm, the appearance size is 358.5 (width) × 296.5 (height) × 15.8 (thickness) mm, and the surface treatment is matte, Hard coating (3H)， The net weight of the product is 1.99Kg (Typ.). In terms of backlight, this product uses 4 pieces of CCFL emitting side entry light sources (top and bottom), with a lifespan of 50K hours and no backlight driver included. The M170EG01 VD adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The M170EG01 V9 has a display resolution of 1280 (RGB) × 1024 (SXGA), an aspect ratio of 5:4 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 337.92 × 270.336 (width × height) mm, the visible size is 341.6 × 274.0 (width × height) mm, the appearance size is 358.5 (width) × 296.5 (height) × 17.5 (thickness) mm, the surface treatment is mirror (Haze 0%), Hard coating (2H), and the net weight of the product is 1.90Kgs (Typ.). In terms of backlight, this product uses 4 pieces of CCFL emitting side entry light sources (top and bottom), with a lifespan of 50K hours and no backlight driver included. M170EG01 V9 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz.

The typical features are sRGB, with a lifespan of over 50000 hours and a matte surface. Its working temperature is 0~50 ° C and storage temperature is -20~60 ° C. This model is suitable for use in computer monitors.
